7.2 View Datalogs
Datalogs may be viewed with the Datalog Viewer software, Microsoft Excel or any other program that can handle tab
delimited values contained in the datalog. The Datalog Viewer software offers a much stronger set of capabilities and
datalogging viewing options; however we understand that many users may wish to use other tools or analysis methods
which do not fall within the scope of the TCM software. The datalog les use the le extension .tlg which is associated
with the Datalog Viewer Software; however this does not prevent users from opening the same le in Microsoft Excel.
To view a datalog, do the following:
1. Select “Datalog” from the le menu and double click “View. Datalogs”
2. A blank screen will appear. Click the “Load” button or go to File->Open and choose the location and name of your
datalog.
3. The datalog initially opens in graph view. o begin viewing the data, click in the boxes next to the data elds you wish
to see near the top of the screen. You may view this data in a tabular view by clicking the “Table View” button.
NOTE: You may also double click the datalog le to open it in the Datalog Viewer software.
ZOOMING
Several zooming options are available by right clicking your mouse button. You may zoom in by clicking on a beginning
time and an ending time for your graph selection. You may also choose to view all the data, zoom to a percentage, or
zoom to a particular time period.
HOTKEYS
Please refer to the hotkeys list for a complete listing of key options for navigating the datalog menu.
You may load another datalog or continue tuning at any time.
use the Communications -> Go Online command or CTRL-G to attempt to connect to the TCM again. If you are still
unable to connect to the TCM, please contact your dealer for support
LIMITED WARRANTY STATEMENT. Powertrain Control Solutions, LLC. Warrants all merchandise against defects in factory
workmanship and materials for a period of 12 months after purchase. This warranty applies to the rst retail purchaser and
covers only those products exposed to normal use or service. Provisions of this warranty shall not apply to Powertrain Control
Solutions, LLC. Product used for a purpose for which it is not designed, or which has been altered in any way that would be
detrimental to the performance or life of the product, or misapplication, misuse, negligence or accident. On any part or product
found to be defective after examination by Powertrain Control Solutions, LLC., Powertrain Control Solutions, LLC. will only repair
or replace the merchandise through the original selling dealer or on a direct basis. Powertrain Control Solutions, LLC. assumes
no responsibility for diagnosis, removal and/or installation labor, loss of vehicle use, loss of time, inconvenience or any other
consequential expenses. The warranties herein are in lieu of any other expressed or implied warranties, including any implied
warranty of merchantability or tness, and any other obligation on the part of Powertrain Control Solutions, LLC., or selling dealer.
