Page 19
Rear Connections
Unit Controls
Ensure all inlets and outlets are connected to correct sources and
applications. All Connections should only be carried out by trained
personnel. Generator must be switched o and unplugged prior to any
cleaning or maintenance operations
1/4" Compression Fitting
6mm Push-Fit Fitting
Mains Cable
Service LED
Power Switch
Pressure Gauge
High Duty LED
WARNING
