Peak 412A - INSTALL ELECTRICAL SYSTEM

20
High limit switch
wire
○
C
Connecting 11
#
& 12
#
(NC) of limit switch to
terminals 3
#
& 5
#
of
control box
When the cross beam is lowered to
300mm, the slider will access to the
drive lever of lower limit switch, and
stop the lift.
51
34
45
3
N. Install electrical system
1. Install high limit switch (See Fig. 45)
2. Install lower alarm limit switch (See Fig. 46)
Fig. 45
Fig. 46
1
40
43
42
61
39
Connecting 13
#
& 14
#
(NO) of limit switch to
terminals 8
#
& 10
#
of
control box
Lower limit
switch wire
○
D
300mm
