Peak 412A - 220 V Circuit Diagram

26
3 Phase
6.3 220V Circuit diagram (See Fig. 55).
Circuit component
Item
Name
Code
Specification
Item
Name
Code
Specification
1
Power switch
QS
380V AC
10
Push button
UP
Duplex
2
Breaker
FU
1
2P
11
Push button
Push button
Down
Triplex
3
Breaker
FU
2
1P
PASS
Duplex
4
Breaker
FU
3
1P
12
Push button
LOCK
Single
5
AC contactor
KM
24V AC
13
Motor
M
Single phase
6
Time relay
KT
24V AC
14
Transformer
TC
24V AC
7
Limit switch
SQ
(1~6)
10A
15
Intermediat
e relay
KA
24V AC
8
Air solenoid
valve
Y2
24V AC
16
Alarm
H
24V AC
9
Hydraulic
solenoid
valve
Y1
24V AC
Fig. 55
Single Phase
