PCAN-Router DR – User Manual
10
3 Operation
3.1 First Steps
Do the following to switch on the PCAN-Router DR:
1. Mount the PCAN-Router DR at the appropriate position on
the DIN rail by hanging it in at the top of the rail and
snapping it to the bottom.
2. Connect each of the two CAN ports with the corresponding
CAN network.
3. If the bit rate is different from the default 500 kbit/s, set the
bit rate with the rotary switch (see section 3.3 on page 11).
The
new bit rate takes effect after reset (see section 3.6 on
pa
ge 14).
4. Connect the PCAN-Router DR to a power supply (8 to 30 V
DC).
The PCAN-Router DR now forwards the CAN messages one on one.
3.2 Status LEDs
The PCAN-Router DR has several status LEDs. Using the standard
firmware, the LEDs have the following meanings:
LED Status Meaning
Off No CAN communication
Green blinking Operational
Status
Red flashing once Reset
Green blinking Data is transmitted CAN 1/CAN 2
Red flashing once Communication error (error frames)
