PCAN-Router DR – User Manual
6
Connections for CAN, RS-232, and power supply via 4-pole
screw-terminal strips (Phoenix)
CAN 1 is isolated up to 5 kV against CAN 2, RS-232, and the
power supply (compliant with IEC 60601-1)
CAN 2 and RS-232 are isolated with 500 V against each other
and against the power supply
Plastic casing (width: 22.5 mm) for mounting on a DIN rail
(DIN EN 60715 TH35)
Voltage supply from 8 to 30 V
Extended operating temperature range from -40 to 85 °C
(-40 to 185 °F)
RS-232 connector for serial data transfer
(reserved for future use)
New firmware can be loaded via CAN interface
1.2 Prerequisites for Operation
Power supply in the range of 8 to 30 V DC
1.3 Scope of Supply
PCAN-Router DR in DIN rail plastic casing
Mating connectors (Phoenix, type: MSTB 2,5/4-ST BK) for both
CAN channels, RS-232, and power supply
Windows development package with GCC ARM Embedded,
flash program, and programming
Library with programming examples
Manual in PDF format
