PCAN-Router DR – User Manual
23
6 Technical Specifications
Connectors
Power Phoenix connector 4-pin
1
CAN 2 x Phoenix connector 4-pin
1
RS-232 Phoenix connector 4-pin
1
Power Supply
Operating voltage 8 - 30 V DC
Supply type External supply
Current consumption Max. 223 mA, typ. 110 mA at 12 V w/o load
Protection ±1 kV surge protection
-60 V reverse polarity protection
±4 kV ESD protection
Microcontroller backup
supply
none
Power saving modes none
CAN
Protocols on OSI layer 2 CAN 2.0 A/B
Physical transmission ISO 11898-2 (High-speed CAN)
Transceiver NXP PCA82C251
CAN bit rates Nominal: 5 kbit/s - 1 Mbit/s
Controller Internal CAN Controller
Supported clock frequencies 60 MHz
Supported bit timing values
Prescaler (BRP)
Time Segment 1
(TSEG1)
Time Segment 2
(TSEG2)
Synch. Jump Width
(SJW)
Nominal
1 -1024
1 - 16
1 - 8
1 - 4
1
Phoenix connector, type MSTB 2,5/4-ST BK, order no. 1756298
