PeakTech 1007 User Manual

8
p. Pulse
(analogue control)
Frequency range :
Amplitude :
Duty cycle :
100mHz ~ 8MHz
0 ~ 10V / 0 ~ -10V / ±10V
100mHz ~ 6MHz : 20% to 80%
6MHz ~ 8MHz : 40 % to 60%
q. Triangle Wave Linearity 99% up to 100KHz
r. Sweep (Linear / Logarithm) Start frequency, stop frequency and sweep step
setting
Sweep type : up, down and up-down
s. Sync Output Frequency
range : Output
level :
Output
impedance
100mHz ~ 8MHz
low level ≤0.6V @ 50Ω high level
≥1V @ 50Ω
50Ω
Modulation Characteristics
a. FSK Function
Frequency range
Internal rate
Source
Sine, Square or Triangle
100mHz ~ 8MHz
400Hz / 1000Hz
Internal / External
b. PSK Function
Frequency range
Phase setting
Internal rate
Source
Sine, Square or Triangle
100mHz ~ 8MHz
0.0000 to 360.0 degree
400Hz / 1000Hz
Internal / External
Trigger/Gate Characteristics
a. Trigger Source Main frequency setting Manual (rotary push) / External:
100mHz ~ 100KHz
b. Gate Source Main frequency setting Manual (rotary push) / External:
100mHz ~ 8MHz
General Characteristics
a. Power Source AC 115V / 230V (on request) ±10%, 50Hz / 60Hz
b. Temperature 0ºC ~ 40ºC (Operation) -20ºC ~ 70ºC (Storage)
c. Relative Humidity up to 80%
d. Dimension 95mm (H) x 235mm (W) x 280mm(D)
e. Weight 3kg
f. Accessories AC power cord, operating manual
PeakTech
®
1014 / 1016 Output Characteristics
a. Frequency
Range
Sine, Square, Pulse and Sync
Output : Triangle :
Ramp Up, Ramp Down :
100mHz ~ 10MHz (P 1014)
100mHz ~ 20MHz (P 1016)
100mHz ~ 1MHz
100mHz ~ 20KHz
b. Frequency
Resolution
100mHz or 6 digits display
