PeakTech 1007 User Manual

9
c. Output
Impedance
50Ω ±5%
d. Amplitude 1mV to 20Vp-p (open-circuit)
0.5mV to 10Vp-p (into 50Ω load)
e. Amplitude
Resolution
3 digits, 1mV min (depending on the attenuation)
f. Amplitude
Accuracy
Typical 1% test at 1KHz 9Vp-p sine @ 50Ω load
g. Output
Attenuation
0, -20, -40 and -60 dB
h. FUNC_OUT Self
Protection
FUNC_OUT short circuit protection
Reverse voltage protection below 20Vpeak
i. DC Offset and
DC Output
±10V at open-circuit, ±5V at 50Ω load
j. DC Output
Resolution
3 digits, ±1mV min (depending on the attenuation)
k. DC Output
Accuracy
1% ±5mV
l. Sine Wave
Harmonic
Distortion
DC ~ 100KHz < -55dBc typical
100KHz to 1MHz < -45dBc typical
1MHz ~ **MHz < -35dBc typical
m. Spurious (non
harmonic)
DC ~ 1MHz < -55dBc typical
n. Total Harmonic
Distortion
DC ~ 100KHz < 0.3%
o. Square Wave rise / fall time  12nS for 10Vp-p @ 50Ω load overshoot < 5% of Vp for
10Vp-p @ 50Ω load
p. Pulse (digital
control)
Frequency range
Amplitude
200mHz ~ 20KHz
20KHz ~ 200KHz
0 ~ 10V / 0 ~ -10V / ±10V
Duty cycle 200mHz ~ 20KHz 1uS ~ 4.995S
20KHz ~ 200KHz 1uS ~ 494.9uS
q. Triangle Wave
Linearity
99% up to 100KHz
r. Sweep
(Linear /
Logarithm)
Start frequency, stop frequency and sweep step setting
Sweep type : up, down and up-down
s. Sync Output Frequency range
Output level
Output impedance
100mHz ~ 10MHz (P 1014)
100mHz ~ 20MHz (P 1016)
low level ≤0.6V @ 50Ω
high level ≥1V @ 50Ω
50Ω
