NION Hardware Manual
June 11, 2012 Version 1.6.4b.1 19
Some text to force a page b reak in W ord but remain inv isible
Cards
NIO-4x4
Four analog mic/line level audio input channels
Four analog line level audio output channels
24 bit A/D (inputs), 24 bit D/A (outputs)
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
NIO-8ml II
Eight analog mic/line level audio input channels
24 bit A/D (inputs)
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
NIO-8i
Eight analog line level audio input channels
24 bit A/D (inputs)
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
NIO-8o
Eight analog line level audio output channels
24 bit A/D (outputs)
48 or 96 kHz audio sampling rate supported
High reliability DIN connector to backplane, using slide rail for alignment
Mini-Euro connectors for easy input connection.
This type of card can be installed in any of the available expansion slots at the rear of the
NION.
NIO-AEC
Eight analog mic/line-level audio input channels with 24 bit A/D
Eight channels of wideband acoustic echo cancellation
