Peavey MediaMatrix Nion User Manual

Appendix C - Technical specifications
92 Version 1.6.4b.1 June 11, 2012
Some text to force a page b reak in W ord but remain inv isible
CobraNet performance
Data Format
16/20/24-bit audio (default = 20)
Protocol
Ethernet with Proprietary CobraNet protocol.
Channels
64 channels at 48kHz
GPIO
Connections
20 ports configurable pins and a fault output via internal
Form-C relay
Digital input
Vin < 0.8VDC = logic 0; Vin > 2.0VDC = logic 1 (1.2V
hysteresis).
Analog input
0.0VDC < Vin < 24.0VDC; 12-bit analog converter precision.
Digital output
logic 0 Vout = 0.0VDC, Isink <= 2mA; logic 1 Vout = 3.3DC,
Isource <= 2mA.
High current outputs
4 ports, each with a 0.5A self-resetting fuse and protection
diodes for driving inductive loads. Vout = 11.5V nominal @
Isource = 0.5A. Direct short protection from ground to +36V.
Relay contacts
Form C contacts rated at 0.3A @ 125VAC or 110VDC, or 1A
@ 30VDC.
Mechanical specifications
Chassis Style
2RU EIA rack package
Installation
EIA rack mount only
Dimensions
19 in. W x 16.8 in. D x 3.5 in. H
Cooling
Forced air, front and side panel intake, rear exhaust.

Peavey MediaMatrix Nion Specifications

General

Brand	Peavey
Model	MediaMatrix Nion
Category	Recording Equipment
Language	English
