5
Rated Power & Load:
30 W RMS into 8 ohms with DDT™ compression
Power @ Clipping: (typically)
(1 kHz, 120 V AC line)
33 W RMS into 8 ohms @ 1% THD
38 W RMS into 8 ohms @ 5% THD
Frequency Response:
+0, -3 dB, 40 Hz to 20 kHz, @ 30 W RMS into
8 ohms
Total Harmonic Distortion:
Less than 0.2%, 100 mW to 30 W RMS, 60 Hz to
10 kHz, 8 ohms, typically below 0.1%
DDT™ Dynamic Range:
Greater than 16 dB
DDT™ Maximum THD:
Below 0.5% THD for 6 dB overload
Below 1% THD for 16 dB overload
Hum & Noise:
Greater than 90 dB below rated power
Power Consumption:
Domestic: 75 W @ 120 V AC, 50/60 Hz
Export: 75 W @ 220/230-240 V AC, 50/60 Hz
Due to our efforts for constant improvements,
features and specifications listed herein are subject to change without notice.
TM
®
SPECIFICATIONS
PREAMP
The following specs are measured @ 1 kHz with the Low , Mid, &
High EQ set @ 5. Nominal levels are with the Pre Gain @ 5.
Minimum levels are with the Pre Gain @ 10.
Preamp Input:
Impedance: High-Z, 220 k ohms
Nominal Input Level: -28 dBV, 40 mV
Minimum Input Level: -47 dBV, 4.5 mV RMS
Maximum Input Level: +6 dBV, 2 V RMS
Preamp Output:
(Phone jack ring)
Function: High level post EQ send
Load Impedance: 10 k ohms or greater
Nominal Output Level: 0 dBV, 1 V RMS (at the
DDT™ limit of 30 W RMS output)
Maximum Output Level: +18 dBV, 8 V RMS
Power Amp Input:
(Phone jack tip)
Function: High level post EQ return
Input Impedance: 22 k ohms
Designed Input Level: 0 dBV, 1 V RMS
Headphone Output:
Load Impedance: 4 ohms or greater
Nominal Power Output: 100 mW into 4 ohms
(Stereo jack, monaural signal, disconnects internal
speaker when phone plug is inserted)
System Hum & Noise @ Nominal Input Level:
(20 Hz to 20 kHz unweighted)
80 dB below rated power
Equalization:
Low, mid, & high passive type
