MIC/LINE INPUT (CH.1-8)
is combination input jack accepts a ¼” or XLR balanced plug. e XLR balanced input is optimized
for a microphone or other low impedance source. e ¼” input is a TRS balanced type, and also accepts
ordinary TS guitar cables.
DIRECT OUT
is impedance-balanced TRS output signal is taken aer the mic preamp, hi pass lter, and compressor,
but before the EQ stage.
AUTO-TUNE ACTIVATION BUTTON AND LED (PV10AT only)
Pressing this button activates the PV10AT's onboard AUTO-TUNE feature. e button illuminates when
in AUTO-TUNE mode (SEE Eects Select {50} and the following page).
GAIN
e Input Gain control is used to establish proper gain structure in the channel. For best results, use the
Solo system (19) to monitor the channel while you set the gain. e goal is maximum gain without distor-
tion. Both the main LED meters (during Solo) and the channel’s Signal/Clip indicator (16,17) can be used
for adjusting gain. If the clip LED (16) comes on and remains lit, try reducing the gain.
150 Hz HI PASS FILTER
e hi pass lter has a corner frequency of 150 Hz. When engaged‚ it can improve clarity by removing
low frequencies that make a mix sound muddy. is feature is especially useful when playing outside on a
windy day or on a hollow-sounding‚ noisy stage. ese kinds of ambient noises can rob your sound system
of power. Engaging this switch will remove those frequencies from the system and restore power where
needed.
COMPRESSION CONTROL (Channels 1 and 2 only)
Adjusting this knob clockwise lowers the threshold of the compressor, thereby increasing the amount of
compression. e compressor ratio is in the 4:1 range, varying with signal levels and the amount of com-
pression. is is useful for controlling peak levels from live sources, and has been designed to subtly tame
the levels of live vocals without noticeable artifacts. e compressor is aer the gain control (5) and the hi
pass lter (4), but before the direct out (2), so it can be patched to external equipment.
Compressor LED
is LED illuminates when the compressor is actively compressing a signal.
Hi EQ
is active tone control (shelving type: ±15 dB) varies the level of the high frequency range.
MID-MORPH EQ (CH. 1-7)
Where most mid-range controls work at just one frequency, the Mid-Morph works at two. When turned
counterclockwise, it cuts at 250Hz to reduce frequencies that muddy the sound. When turned clockwise,
it boosts at 4kHz to add intelligibility to vocals. Either way, improved vocal or instrument denition can
be achieved.
Low EQ
is active tone control (shelving type: ±15 dB) varies the level of the low frequency range. Caution: Ex-
cessive low frequency boost causes greater power consumption and increases the possibility of speaker
damage.
EQ BYPASS
Engaging this button bypasses the equalization of the channel, allowing you to easily hear the eect of
the EQ settings.
AUX SEND
is control adjusts the level of the channel signal sent to the Aux output. e signal is taken before the
channel level (18) but aer the channel EQ, meaning that changes to the EQ settings will aect the aux
mix, but changes to the channel level control won't. Typical use for the Aux bus is to feed stage monitors,
when used in a live performance, or to feed headphone ampliers in a recording situation.
1
2
3
4
5
6
8
9
10
11
12
13
14
15
18
19
7
16
17
PV10AT Front Panel (channels 1 and 2)
