PV10AT/PV10BT Front Panel (channels 5, 6, 7 and 8)
22
23
26
28
29
24
25
27
30
22
23
24
25
26
27
28
3.5mm STEREO INPUT
e 3.5mm input to channel 5/6 accepts a stereo input from the output of an MP3 player,
CD player, tape deck or other similar device. is input is optimized for portable hand-
held devices and therefore has very high sensitivity.
STEREO INPUTS
Channels 5 and 6 also feature 1/4" inputs. If only one jack is used, it behaves as a mono
source with a pan control. When both jacks are connected, these connections serve as a
stereo source with a balance control; 5 is Le and 6 is Right.
USB MEDIA JACK
A-type USB connector that a removable data storage device can be connected to playback
music
USB PLAYBACK:
First, slide the input selection switch (27) to the USB A position. e bottom of the LCD
display will say “Insert USB drive”. Insert your USB drive into the USB Media Jack (24)
at the top of channel 7/8. e Media Player will now enter "Folder Navigation Mode". In
this mode, you can scroll through a list of all folders on the USB drive. Once you select
a folder, the Media Player will enter "Song Navigation Mode" which allows you to scroll
through a list of all songs contained in the selected folder. If there are no songs in the
selected folder, the LCD will display "No Songs". To return to Folder Navigation Mode, scroll
to the very beginning of the list and select the <FOLDERS> option.
Once a song is nished playing, the Media Player will automatically start playing the next
song. Once the Media Player reaches the last song, it will automatically loop back to the
beginning of the list.
BLUETOOTH PAIRING BUTTON AND LED
e Bluetooth Pairing Button is used to turn on/o the Bluetooth. e blue “Bluetooth Active
LED” indicates the status of the Bluetooth connection. If the LED is o, the Bluetooth module
is powered o. If the LED is slowly ashing, the PV mixer is not paired with any device, but is
available for connection. When the LED is lit solid, the source device is properly paired to the
mixer and ready to play.
To clear the paired device memory, make sure Bluetooth is on and press and hold the Blue-
tooth Pairing Button for 5 seconds. e PV mixer will ask if you would like to clear the Blue-
tooth memory. Select "Y" using the Media Select knob to clear the memory. e PV mixer will
go through the process of clearing the memory, which should take approximately 15 seconds.
RCA MEDIA INPUTS
e RCA inputs to channel 5/6 accept a stereo source such as an MP3 player, CD player,
tape deck or other similar device. is input is optimized for portable handheld devices
and therefore has very high sensitivity.
DIGITAL SOURCE SELECTOR
is switch selects between USB A (24), USB B (68), and the internal Bluetooth receiver.
MID CONTROL
Stereo channels' midrange is +/-20 dB @ 440Hz ; the HIGH (8) and LOW (10) controls are
described above.
