13
Preamp High Gain Input:
Impedance: Very High-Z, 470 kΩ
Preamp Low Gain Input:
(-10 dB Pad)
Impedance: High-Z, 68 kΩ
Effects Send:
Low Impedance: High-Z, 22 kΩ
or greater
Nominal Output Level: 0 dBV,
1.0 V(rms)
Effects Return:
Impedance: Very High-Z, 1 MΩ
Designed Input Level: 0 dBV,
1.0 V(rms)
Equalization: (Clean channel only)
Custom Low, Mid, & High passive EQ
Push Bright: +6dB @ ~3.5kHz
Equalization: (Lead channel only)
Custom Low, Mid, & High passive EQ
Lead Channel Front Panel
Footswitch Functions:
Push Gain: Increase Gain in Lead
channel and introduces a tighter low
end response
Push Volume: +3-5dB Volume boost
(more effect at midway Lead Volume
settings)
Remote Footswitch: (optional)
Special 2-button unit with LED
indicators (#00579720) for channel
selection (Channel) and a special
preset Volume Boost and/or Gain
Boost function selectable via the
front panel GAIN (7) and
VOLUME (10) switches described
above (BOOST)
Valve King
™
Series Specications
Rated Power:
50 W(rms) into 16 Ω
Power Consumption:
(Domestic)
150 W, 50/60 Hz, 120 VAC
Tube Complement:
2 x 6L6GC, 3 x 12AX7/ECC83
Dimensions (H x W x D):
18.25" x 21.38" x 10.25"
Weight:
44.5 lbs.
Valve King™ 112
Rated Power:
100 W(rms) into 4, 8, or 16 Ω
Power Consumption:
(Domestic)
300 W, 50/60 Hz, 120 VAC
Tube Complement:
4 x 6L6GC, 3 x 12AX7/ECC83
Dimensions (H x W x D):
9.75" x 26.50" x 11.13"
Weight:
41.0 lbs.
Valve King™ 100 Head
Rated Power:
100 W(rms) into 4, 8, or 16 Ω
Power Consumption:
(Domestic)
300 W, 50/60 Hz, 120 VAC
Tube Complement:
4 x 6L6GC, 3 x 12AX7/ECC83
Dimensions (H x W x D):
20.63" x 26.50" x 11.13"
Weight:
68.5 lbs.
Valve King™ 212
Features and specifications subject to change without notice.
Valve King™ Series 100/112/212 Preamp Specifications
NOTE: At any front panel settings, adjust the TEXTURE (#21) knob on the rear of the unit to
attain the desired level of power amp distortion, harmonics, and power sensitivity.
