5.5-5.7 Protection Instructions
NO .
Test Project
Specification
Unit
Remark
5.5
Inverter
5.5.1
Over Temperature
Inverter
cooling≥65℃
℃
Lock，AC No
output,Until the
temperature drops
5.5.2
Over Load
＞1500
W
Locked, no output,
until disconnected
and restart
5.5.3
AC Output Short
Circuit
—
W
Locked, no output,
until disconnected
Remark
When 5.5.2 ,5.5.3 in the protection state, the AC current switch needs to
be turned off. When it is turned on again, the AC output will be turned on.
5.6
Controller
5.6.1
USB Over Current
3
A
Output shut down
5.6.2
DC12V Output Over
Current Protection
15
A
Output shut down
5.6.3
Solar charging
protection
29.2-29.7
V
Stop charging after
achieve voltage
5.7
Battery Pack
5.7.1
Single-cell overcharge
voltage protection
4.2 V
V
Disconnect input，
keep output
5.7.2
Single-cell
over-discharge voltage
protection
2.8V
V
Shut down output
5.7.3
Battery pack
over-temperature
protection
≥65
℃
Shut down input
and output
5.7.4
Short circuit protection
Yes
Shut down output
