SA752PU
Description Qty. Part #
A
wall arm assembly 1 095-P1715
B
universal adapter bracket 1 095-P1635-2
C
wood screws 3 520-1202
D
concrete anchors 3 590-0320
E M10 x 15 mm socket head screw
2
520-9262
F fastener caps
3
590-1324
G cable ties
8
590-1168
H
6 mm allen wrench 1 560-9716
I
5 mm allen wrench 1 560-9640
J
rear cable cover 2 590-P1326
K
front cable cover 2 590-P1327
L
#3 screwdriver bit (not shown) 1 560-0209
M
5/32 allen wrench 1 560-9646
Parts List
Parts may appear slightly different than illustrated.
Before you begin, make sure all parts shown are included with your product.
