ISSUED: 05-11-05 SHEET #: 201-9476-5 05-10-06
I
M
D
E
F
L
A
B
C
HG
J
K
N
O
ST 632P, ST 632P-S, ST 632 ST 632-S
RTFPT 632 RTFPT 632-S
Description Qty Part # Part # Part # Part #
A
hook bracket 1 095-1346 095-4346 095-1346 095-4346
B
tilt assembly 1 095-0359 095-0360 095-0359 095-0360
C
adapter plate 1 095-1322 095-4322 095-1322 095-4322
D
Alligator® anchor 2 590-0097 590-0097 590-0097 590-0097
E
M4 x 10 mm phillips screw 4 504-9012 504-9012 504-9012 504-9012
F
M4 x 20 mm phillips screw 4 504-9020 504-9020 504-9020 504-9020
G
M6 x 12 mm phillips screw 4 520-1128 520-1128 520-1128 520-1128
H
M6 x 20 mm phillips screw 4 520-9402 520-9402 520-9402 520-9402
I
M6 x 30 mm phillips screw 4 510-9109 510-9109 510-9109 510-9109
J
M5 x 6 mm phillips screw 5 520-1023 520-1023
K
#10 washer 4 540-9400 540-9400 540-9400 540-9400
L
retaining spacer 4 590-5005 590-5005 590-5005 590-5005
M
#14 x 2-1/2" hex head wood screw 2 5S1-015-C03 5S1-015-C03 5S1-015-C03 5S1-015-C03
N
M5 x 6 mm socket pin screw 1 520-1114 520-1114
O
4 mm securtiy driver 1 560-1133 560-1133
Parts List
