REPAIR PARTS
Table 13.1: General Repair Parts – PFC-460
Description
Quantity
Required
Stock
Code
1 Panel, Jacket Front Door, with Ball Studs 1 54256
2 Lens for Jacket Front Door 1 54167
3 Display Module 852RT- PFC-460/1500 1 54735
4 Gasket for Display Bracket 1 54513
5 Bracket for Display Module 1 PF2007-1
6 Hex Nut, #6-32 with Lock washer (Local Hdwr Supply) 2 51553
7 Screw, #6-32 x 1/2" LG Phillips Head, (Local Hdwr Supply) 2 5449
8 Screw, #10 x 1/2" Lg. Hex Head, (Local Hdwr Supply)
4 99992
9 Cover Plate
1 PF6088
10 Cover Plate Gasket
1 54680
11 Jacket, Lower Front Panel 1 PF6051
12 Bulk Head Fitting for Condensate Hose 1 54140
13 Gasket for Bulk Head Fitting 1 54134
14 Leg Leveler 4 5429
15 Coupling, 1-1/2" NPT Brass – PF-460 (Local Hdwr Supply) 2 5551
16 Nipple, 1-1/2" NPT x 14" LG Brass – PF-460 (Local Hdwr Supply) 2 5550
17 Elbow, 1-1/2" NPT Brass – PF-460 (Local Hdwr Supply) 1 5553
18 Tee, 1-1/2" NPT Brass – PF-460 (Local Hdwr Supply) 1 5554
19 Nipple, 1-1/2" NPT x 3" Brass – PF-460 (Local Hdwr Supply) 2 5552
20 Bushing, 1-1/2" x 3/4" NPT Brass – PF-460 (Local Hdwr Supply) 1 5556
21 Shut-off Valve, 3/4" NPT Brass, (Local Hdwr Supply) 1 50764
22 Convenience Outlet 1 54136
23 Hex. Nut, #8-32 with Lockwasher, (Local Hdwr Supply) 4 51573
24 Control Module 852MT – PFC-460 1 54685
25 3.15Amp, 250V 5x20mm Slow-Blow Glass Fuse, Radio Shack-270-1067 1 5650
26 Rocker Switch - 20Amp 1 5701
27 Pump Isolation Relay Module Kit (Includes harness) 1 54610
28 10Amp,125V 5x20mm Slow-Blow Glass Fuse, Radio Shack-270-152 4 —
29 Vent/Air Inlet Adapter – PFC-460 1 54294
30 Vent Adapter Gasket – PFC-460 1 54217
31 Screw #10 x 3/4" Long Phillips Pan Head 6 5611
32 Heat Exchanger Outlet Collar 4" PFC-460 1 5532
33 Condensate Neutralizer Assembly 1 54204
34 Condensate Receiver Assembly 1 54259
35 Blocked Vent Switch Kit - Include Items #36 & #37 1 54260
36 1/4" ID PVC Tubing x 12" Long 1 5697
37 90° Barbed Elbow - Polypropylene Adapter Fitting 1 5698
38 Gasket - Cover Plate 1 54141
39 Cover Plate for Thermal Temperature Switch 1 PF2021
40 High Temperature Limit Switch - Tasseron TSDS950 - 95C 1 54419
41 Supply/Return Sensor - 12 KΩ Tasseron TSD00BS 1 54418
42 Flue Sensor Grommet - EPDM 1 54291
43 Flue Sensor - 12 KΩ Tasseron TSD20B0 1 54209
