PELLENC BATTERY 250

56_158890-D

4.6. TOOL CONNECTION

Note

For more information on connecting the tool to the battery, refer to the tool's operating instructions manual.

4.7. PUTTING THE LEAD AND ARMBAND IN PLACE

1. Put on the harness and install the connected tool

in the holster, see 4.5. Fitting the holster to the

harness, page 14 and 4.6. Tool connection,

page 16.

2. Put the armband (1) around your arm.

3. Insert the tool power cord (2):

• in parallel if it is to slide into the armband clip (3);

• perpendicularly if it is to be attached in the

armband clip (3).

4. Connect the tool power cord (2) to the tool, see 4.6.

Tool connection, page 16

5. Put the tool in the holster.
