Pelpro PPC90 - Exhaust Blower Not Coming on

28 06/218390-017A
EXHAUST BLOWER NOT COMING ON
CLEAN THE EXHAUST
BLOWER AND MAKE SURE
IT SPINS FREELY
CONNECT MULTIMETER IN
VAC TO WIRE TEST PORTS
SHOWN ON THE NEXT PAGE.
DOES THE METER SHOW AT
LEAST 100 VAC?
APPLIANCE
REPAIRED
ARE WIRES
PLUGGED INTO
THE BLOWER?
YES
NO
REPLACE
CONTROL
BOARD
YES
NO
YES
REPLACE
EXHAUST
BLOWER
REPLACE
EXHAUST
BLOWER
NO
RECONNECT WIRES
DOES BLOWER
RUN
NO
YES
Test points on next page
