Pelpro PPC90 - No Power

34 06/218390-017A
NO POWER
CHECK THE WALL
OUTLET FOR POWER
DISCONNECT
APPLIANCE FROM
WALL POWER
AND RESET THE
SNAP SWITCH BE
PRESSING THE
MANUAL RESET
BUTTON IN THE
CENTER OF THE
SWITCH
IS THE
FUSE ON THE
CONTROL
BOARD GOOD?
SYSTEM IS
REPAIRED
IS THE
SNAP DISC
ON THE
AUGER TUBE
TRIPPED?
IS THE
APPLIANCE
FUNCTIONING?
MAKE THE REPAIR
BY EITHER FIXING
THE CONNECTION
OR REPLACING THE
COMPONENT.
CHECK WIRE
CONNECTIONS
GOING INTO
THE CONTROL
BOARD.
REPLACE THE
CONTROL BOARD
WIRE HARNESS HAS
TO BE INSPECTED FOR
A SHORT. CONTROL
BOARD MAY ALREADY
BE DAMAGED
YES
NO
YES NO
NO
GOOD
NO
YES
