Installing Your Stove
Installing Your Stove
Pro Tips
• See venting manufacturer’s required clearances to combustibles
• F or h ori z on tal i n stallati on s, th e mi n i mu m clearan ce f rom ex teri or to termi n ati on cap i s 6” — y ou
may w an t to i n crease to 18 ” clearan ce to mi n i mi z e soot b low b ack on h ome ex teri or.
Install venting. (For additional installation options visit pelprostoves.com)
3
Install wall thimble (sold separately) per manufacturer requirements.
2
V erti cal - I n teri or, Pref erred I n stallati on
6 in.
(1 5 2 mm)
M in.
Clean- out T
Firestop
Flashing
R ain Cap
N on- combustible H earth Pad
1 2 in. (30 5 mm) M inimum
Ceiling Support
Follow pipe manufacturer
listed clearance
E xt eri or - O pti on al I n stallati on s
N on- combustible
H earth Pad
W all Thimble
H oriz ontal
Termination Cap
Termination
Cap
6 in. (1 5 2 mm)
M inimum
6 in.
(1 5 2 mm)
M inimum
Clean Out T
W all Thimble
6 in.
(1 5 2 mm)
M inimum
Venting Your Stove
CAUTION!
T ake appropri ate precau ti on s to locate u ti li ti es w i th i n th e w all an d avoi d con tact.
WARNING!
D o n ot termi n ate ven ti n g i n an y en closed or semi -en closed area
su ch as: a carport, g arag e, atti c, craw l space, u n d er a su n d eck
or porch , n arrow w alkw ay or closely f en ced area, or an y locati on
th at can b u i ld u p a con cen trati on of f u mes su ch as a stai rw ell,
covered b reeze w ay , etc.
CAUTION!
E n su re th at yo u r stove ven ti n g termi n ates ab ove
yo u r stove. T h e f ollow i n g may occu r:
• Y ou r stove appli an ce w i ll n ot d raf t properly
• Smoke may seep i n yo u r h ou se
• E xce ssi ve sooti n g
Install vent at clearances specied by the manufacturer
Use silicone to create an effective vapor barrier at the location where the chimney or
other component penetrates to the exterior of the structure.
4
NOTE: In Canada when using a factory-built chimney it must be safety listed, Type UL103 HT (2100
o
F) CLASS “A” or
conforming to CAN/ULC-S629M, STANDARD FOR 650
o
C F A CT O R Y -B U I L T CH I M N E Y S.
Mark and cut wall for venting penetration on exterior wall (if needed).
1
