3.25 PORT G: 10-Pin Debug Connector (Power MPC5xx/8xx)
The Cyclone provides a standard 10-pin 0.100-inch pitch dual row 0.025-inch square header for
Power MPC5xx/8xx BDM targets. The location of the this header is indicated as PORT G in Figure
3-5.
Power MPC5xx/8xx BDM Pinout
N/C 12SRESET#
GND 34DSCLK
GND 56N/C
HRESET# 78DSDI
VDD 910DSDO
3.26 PORT H: 20-Pin Debug Connector (Kinetis, S32 (ARM), other P&E-Supported ARM
devices)
The Cyclone provides a 20-pin 0.100-inch pitch double row connector for ARM targets. The
location of the this header is indicated as PORT H in Figure 3-5. The 20-pin standard connector
pin definitions for JTAG mode are as follows:
20-Pin Standard Connector JTAG Mode Pin Assignments
PIN 1 - TVCC NC - PIN 2
PIN 3 - TRST or NC GND - PIN 4
PIN 5 - TDI GND - PIN 6
PIN 7 - TMS GND - PIN 8
PIN 9 - TCK GND - PIN 10
PIN 11 - NC GND - PIN 12
PIN 13 - TDO GND - PIN 14
PIN 15 - RESET GND - PIN 16
PIN 17 - NC GND - PIN 18
PIN 19 - NC GND - PIN 20
The Cyclone Universal and Cyclone Universal FX also support SWD Mode. This replaces the
JTAG connection with a clock and single bi-directional data pin.
20-Pin Standard Connector SWD Mode Pin Assignments
PIN 1 - TVCC NC - PIN 2
PIN 3 - TRST or NC GND - PIN 4
PIN 5 - NC GND - PIN 6
PIN 7 - TMS/SWDIO GND - PIN 8
PIN 9 - TCK/SWCLK GND - PIN 10
PIN 11 - NC GND - PIN 12
PIN 13 - NC GND - PIN 14
PIN 15 - RESET GND - PIN 16
PIN 17 - NC GND - PIN 18
PIN 19 - NC GND - PIN 20
SWD Mode is selected from the “Communication Mode” drop-down box in the Cyclone Image
Creation Utility:
