Cyclone Universal & Cyclone Universal FX - User Manual 62
13 CYCLONE ERROR CODES
The Cyclone Universal and Cyclone Universal FX will indicate errors using the following codes.
Please contact P&E if instructed or if you are unsure of the specific meaning of an error code.
13.1 Debug Mode Communication Errors
$0001: No target response
$0002: Invalid target response
$0003: Wait for target response canceled
$0004: Wait for target response failed
$0005: Error detecting communication speed
$0006: Failed to unsecure target
$0007: Error entering debug mode
$0008: Error entering debug mode while target is secured
$0009: Error entering debug mode for verification
$000A: Error writing a block of data to target
$000B: Error enabling or disabling module
$000C: Error in performing timing test
$000D: MON08 target had an invalid reset
$000E: Vendor hardware mismatch
$000F: Error generating high voltage
13.2 SAP Image Handling Errors
$0011: SAP image ID is greater than total number of images
$0012: Error during SAP image validation
$0013: SAP operation was not configured
$0014: SAP image storage was not initialized
$0015: SAP image transfer error, invalid data length
$0016: SAP image transfer error, invalid start address
$0017: SAP image transfer error while writing to storage
$0018: Error writing serial number structure storage
$0019: Error writing LCD menu structure storage
$001A: Error erasing storage block
$001B: SAP image requires higher firmware version
$001C: SAP image version not supported
$001D: Out of RAM memory, try reset
13.3 SAP Communication Handling Errors
$0031: System reset occurred (out of reset for host-controlled operations)
13.4 SAP Algorithm Header Operation Handling Errors
$0061: Undefined algorithm header operation, check software and firmware versions
$0062: Algorithm header operation failure, check software and firmware versions
