Cyclone Universal & Cyclone Universal FX - User Manual 52
This displays the type of Cyclone hardware.
(11 Gateway IP Number
The IP number of a gateway on the network.
(12) Subnet Mask
The subnet mask of the network.
(13) Firmware Version
A read-only field which returns information pertaining to the build date and firmware version of
the Cyclone device.
(14) FPGA Version
A read-only field which returns the hardware version of the FPGA.
(15) Program Cyclone Parameters
This button saves the information as it appears in the "Reconfigure IP Numbers" area onto the
Cyclone device.
8.6.1 LCD Home Screen Display Selection
The lower area of the Cyclone IP Configuration Utility contains the LCD Home Screen Display
Selection Area. This allows users to configure the Cyclone to display specific items on the
Cyclone’s home screen. Users may select items from the Available Display Options window and
use the arrow button to add them to the Display Options Selected window. Up to 7 items may be
selected. Press OK to save the selections, or press Clear to clear them. Information corresponding
to the selected items will be displayed on the home screen.
8.7 Using Cyclone IP Configuration Utility To Configure The Cyclone
Before the Cyclone is ready to communicate over an Ethernet network, it will need to be configured
with the relevant network parameters. The application that provides this capability is the Cyclone
Configuration Utility (IPSetup.exe), and is provided as part of the standard Cyclone Universal and
Cyclone Universal FX software distribution.
In order to update the network parameters, perform the following steps:
1. Connect a Cyclone to the PC via a serial or a USB cable, and make sure that it is powered
before launching the Cyclone Configuration Utility. The Cyclone Configuration Utility starts
up with the following screen:
