Cyclone Universal & Cyclone Universal FX - User Manual 3
High-Speed
Target
Communications
Cyclone Universal Cyclone Universal FX
Very fast Extremely fast: Up to 25 Mb/s
Powerful
LCD Menu
Cyclone Universal Cyclone Universal FX
• Executes SAP operations
• Selects SAP image
• Configures Cyclone IP settings
• Displays operation status
Multiple
Communications
Interfaces
Cyclone Universal Cyclone Universal FX
USB 2.0 Full Speed USB 2.0 High-Speed
• Ethernet: 10/100 baseT
• Serial Baud 115200, no parity, 8 data bits,
1 stop bit (adjustable to 57600 Baud for
RS232 controlled production environment)
Additional
Storage - SDHC
Memory Card
Support
Cyclone Universal Cyclone Universal FX
- • SDHC Port
• SD Card can store more than
200 images.
Versatile
Power
Management
Cyclone Universal Cyclone Universal FX
• Uses electromechanical relays to
automatically cycle target power when
necessary.
• Jumper-settable power management
schemes.
Multiple
Voltage
Operation
Cyclone Universal Cyclone Universal FX
• Automatically detects and caters to target
voltages ranging from 1.8V to 5V.
Multiple Target
Communication
Modes
Cyclone Universal Cyclone Universal FX
• Supports the following communications modes:
– 6-Pin Regular Debug Connector BDM/JTAG Mode
– 10-Pin Regular Debug Connector BDM/JTAG Mode
– 14-Pin Regular Debug Connector Nexus/JTAG Mode
– 16-Pin Regular Debug Connector MON08 Mode
– 20-Pin Regular Debug Connector JTAG/SWD Mode
– 26-Pin Regular Debug Connector BDM/ JTAG Mode
– Mini 10-Pin Mini Debug Connector JTAG/SWD Mode
– Mini 20-Pin Mini Debug Connector JTAG/SWD Mode
• User-selectable target communication speed.
Cyclone Universal & Cyclone Universal FX Features
