Original settings
Maintenance record book
Installation settings
1
Installation no.
2
: Installation date
3
:
Resin type
4
: Resin volume
5
:
Valve serial no.
6
: Outlet water hardness
7
: [°tH]
Tank size
8
: [°tH] Brine tank size
9
: [L]
Hydraulic settings
10
Injector size
11
: DLFC size
12
:
Refill controller number
13
: BLFC size
14
:
Electrical settings
15
Voltage
16
: [V] Frequency
17
: [Hz]
Power
18
: [W]
Software settings
19
Regeneration time
20
: Day of the week
21
:
Days between regen.
22
: Qty of salt per regen.
23
: [kg]
System capacity
24
: [m
3
°tH] Inlet water hardness
25
: [°tH]
Cycle 1
26
: [min] Cycle 2 : [min]
Cycle 3 : [min] Cycle 4 : [min]
Cycle 5 : [min] Cycle 6 : [min]
Cycle 7 : [min] Cycle 8 : [min]
Date
27
Description
28
Replaced parts
29
Name
30
Signature
31
