FLECK 7000SXT Service Manual • 3
JOB SPECIFICATION SHEET
NOTE: Some options may not be available depending on
valve model or other options chosen.
Job Number: _____________________________________________________
Model Number: ___________________________________________________
Water Hardness:_________________________________________ppm or gpg
Capacity Per Unit: _________________________________________________
Mineral Tank Size: ________________________________________________
Diameter: _______________________________________________________
Height: __________________________________________________________
Salt Setting per Regeneration: _______________________________________
1. Type of Timer:
A. 7 Day or 12 Day
B. Meter Initiated
2. Downflow Upflow Upflow Variable
3. Meter Size:
A. 3/4” Std Range (125 - 2,100 gallon setting)
B. 3/4” Ext Range (625 - 10,625 gallon setting)
C. 1” Std Range (310 - 5,270 gallon setting)
D. 1” Ext Range (1,150 - 26,350 gallon setting)
E. 1-1/2” Std Range (625 - 10,625 gallon setting)
F. 1-1/2” Ext Range (3,125 - 53,125 gallon setting)
G. 2” Std Range (1,250 - 21,250 gallon setting)
H. 2” Ext Range (6,250 - 106,250 gallon setting)
I. 3” Std Range (3,750 - 63,750 gallon setting)
J. 3” Ext Range (18,750 - 318,750 gallon setting)
K. Electronic________Pulse Count________Meter Size
4. System Type:
A. System #4: 1 Tank, 1 Meter, Immediate, or Delayed Regeneration
B. System #4: Time Clock
C. System #4: Twin Tank
D. System #5:
2-5 Tanks, Interlock Mechanical
2-4 Tanks, Interlock Electronic
Meter per unit for Mechanical and Electronic
E. System #6:
2-5 Tanks, 1 Meter, Series Regeneration, Mechanical
2-4 Tanks, 1 Meter, Series Regeneration, Electronic
F. System #7:
2-5 Tanks, 1 Meter, Alternating Regeneration, Mechanical
2 Tanks only, 1 Meter, Alternating Regeneration, Electronic
G. System #9: Electronic Only, 2-4 Tanks, Meter per Valve, Alternating
H. System #14: Electronic Only, 2-4 Tanks, Meter per Valve.
Bring units on and offline based on flow.
5. Timer Program Settings:
A. Backwash _____________________________________ Minutes
B. Brine and Slow Rinse: ____________________________ Minutes
C. Rapid Rinse: ___________________________________ Minutes
D. Brine Tank Refill: ________________________________ Minutes
E. Pause Time: ____________________________________ Minutes
F. Second Backwash: ______________________________ Minutes
6. Drain Line Flow Control:_____________________________ gpm
7. Brine Line Flow Controller: __________________________ gpm
8. Injector Size#: ___________________________________
9. Piston Type:
G. Hard Water Bypass
H. No Hard Water Bypass
