6
Replacing the IntelliBrite LED light assembly
1. Turn off main electrical switch or circuit breaker, as well as the switch which operates the IntelliBrite LED
underwater light itself.
2. Before starting make sure that you have a new lens gasket (P/N 79101600) and a IntelliBrite LED pool light
assembly ready to install.
WARNING - Replace the LED light assembly with the same type and wattage. Failure to replace the
LED light assembly with the same type will damage the LED light assembly and may cause an electrical
hazard resulting in death or serious injury to pool users, installers, or others due to electrical shock, and
may also cause damage to property.
WARNING - Always install a new lens gasket (P/N 79101600) whenever disassembling the IntelliBrite
LED light assembly. Failure to do so may permit water to leak into the assembly which could cause:
(a) an electrical hazard resulting in death or serious injury to pool users, installers, or others due to electrical
shock, or
(b) breakage of the lens, which likewise could result in serious injury to pool users, installers, or
bystanders, or in damage to property.
3. REMOVING THE INTELLIBRITE LED LIGHT: Remove the pilot screw at top of face ring, remove the light
assembly from the niche. Place the assembly on the deck. Note: It is not necessary to drain down the pool.
WARNING - Be sure to keep the pilot screw from the IntelliBrite LED underwater light. This screw
mounts and electrically grounds the housing securely to the mounting ring and wet niche. Failure to use the
screw provided could create an electrical hazard which could result in death or serious injury to pool users,
installers or others due to electrical shock.
D A N G E R !
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION
Always disconnect power to the pool light at the circuit breaker before
servicing the light. Failure to do so could result in death or serious injury to
installer, serviceman, pool users, or others due to electrical shock.
Pilot screw
