12 EQUIPMENT INSTALLATION
Rev E
Figure 3
Performa Valve Identification
Refill Controller
Regenerant Tube Connection
Injector and cap
Valve Discs
Outlet
Drain
Inlet
Backwash
Injector Screen
Camshaft
Drain Control
Filter
Control Module
Mount
One Piece Valve
Disc Spring
Motor
Optical Sensor
