Pool and Spa Heater Installation and User’s Guide P/N 475106 Rev. A 2/2014
Technical Data
| Technical Data
i
0087
1312
THIS HEATER IS EQUIPPED TO BURN
OUTPUT
ALTITUDE
MINIMUM CLEARANCE FROM COMBUSTIBLE
CONSTRUCTED 15 CM REAR, 15 CM TOP.
DO NOT INSTALL THIS HEATER UNDER AN OVERHANG
LESS THAN 1 METER FROM THE TOP. THE AREA UNDER
THE OVERHANG MUST BE OPEN ON THREE (3) SIDES.
APPROVED FOR INDOOR AND OUTDOOR INSTALLATIONS ELECTRICAL COMPLIANCE: IN ACCORDANCE
WITH LOCAL ELECTRICAL CODES.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE BRITISH STANDARD INSTALLATION
CODES, AND WITH THE REQUIREMENTS OF THE AUTHORITY HAVING JURISDICTION.
REFER TO THE OPERATING INSTRUCTIONS FOR
APPROVED WATER TREATMENT.
TYPE G23
DESIGN AND MANFACTURED BY PENTAIR WATER POOL AND SPA, INC.
INPUT RATE
MASTERTEMP
™
POOL HEATER
GAS
Qn= 100 kW
2000 m
Pn= kW
P/N 461077.A.TAB
200 HD 300 HD 400 HD
Qn= 53 kW
Qn =79 kW
Pn= kW Pn= kW
2000 m 2000 m
Model
General Specifications
GAS CATEGORY: II
GAS TYPES: 2H (G20) Natural Gas; 3P (G31) Propane Gas
GAS SUPPLY PRESSURE: G20 @ 20 mbar, G31 @ 37mbar
TYPE OF APPLIANCE: G23
COUNTRY OF DESTINATION: GREAT BRITIAN
WARNING!
READ THE TECHNICAL INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE.
READ THE INSTALLATION AND USER’S GUIDE BEFORE LIGHTING THIS APPLIANCE.
0087
1312
Label P/N 475105.A.TAB
