The following removal and installation instructions describe how to remove and install the
MicroBrite
light assembly.
1.
Switch off electrical switch or circuit breaker at the source,
2.
Remove Junction Box or T
ransformer cover. Disconnect the light wires and
attach a fish tape to the existing light power cord.
This will assist in pulling the
replacement light power cord through the conduit back to the junction box.
3.
Remove the MicroBrite light assembly from the pool or spa water:
Using
the provided installation tool (P/N
620458), rotate the light assembly counter-
clockwise 1/8 of a turn to release the light from the wall fitting.
4.
Slowly pull the light and attached power cord (with attached fish tape) out of
the wall fitting. Pull the light’
s power cord and fish tape out of the wall fitting and
place the light on the deck.
5. Attach the new light power cord to the fish tape and carefully feed the fish tape
and cable to the junction bo
x.
6.
Install the light into the wall fitting:
See page 7 -10 for light installation
instructions.
7.
Connect the two (2) conductors to the corresponding circuit wires in the
Junction Box:
See page 11 for light wiring instructions.
8.
Final check:
See page 11 for final check instr
uctions.
Failure to bring the pool or spa’s electrical system up to code requirements before
installing the underwater light will create an electrical hazard which could result in
death or serious injury to pool users, installers, or others due to electrical shock, and
may also cause damage to property.
IMPORTANT NOTICE: THE MICROBRITE LIGHT IS A
NON-SERVICEABLE LIGHT. THE COMPLETE LIGHT ASSEMBLY
MUST BE REPLACED.
IMPORTANT NOTICE:
THE MICROBRITE
™
COLOR AND WHITE LED LIGHT IS A
NON-SERVICEABLE LIGHT. THE COMPLETE LIGHT ASSEMBLY
