BRINE WELL ASSEMBLY CH15675
Item No. QTY Part No. Description
1 ........... 1 .......CH15675 ....... Brine Well Assembly
A.......................................... Brine Well w/Slots
B ......................................... Safety Brine Valve
C ......................................... Grommet
D ......................................... Brine Tube 3/8" x 60"
E ......................................... Cap, Brine Well 4" Dia.
(Caplug STP-4)
F .......................................... Brine Float w/One Grommet
(As purchased)
G ......................................... Air Check Assembly
H ......................................... Tubing Insert, Brass
2 ........... 1 .......CH34413 ....... Cover and Brine Tank
3 ........... 1 .......CH20774 ....... Brine Tank Overow Fitting
Assembly
4 ........... 1 .............................. Tubing, 12 Foot, 1/2" ID,
Drain Line
5 ........... 1 .............................. Clamp, Hose
4
A
E
5
1
3
2
G
F
H
D
C
B
H
OM26K • 15
