© 2008 Pentair Water Pool and Spa, Inc. All rights reserved
This document is subject to change without notice
Trademarks and disclaimers: Ultra-Flow
®
and Pentair Pool Products
®
are trademarks and/or registered trademarks of Pentair Water Pool
and Spa, Inc. and/or its afliated companies. Unless noted, names and
brands of others that may be used in this document are not used to
indicate an aflitation or endersement between the proprietors of these
names and brands and Pentair Water Pool and Spa, Inc. Those names
and brands may be the trademarks of those parties or others.
Customer Support
HERENTALS, BELGIUM (8:30 A.M. to 4:30 P.M.) CET
Phone: + 32 (0) 14 25 99 11
Website: www.pentairpooleurope.com
Declaration of Conformity
We declare, under our sole responsibility, that the product identi-
ed in this declaration, and to which this declaration relates, are in
conformity with the protection requirements of Council Directive 98/
37/EEG
The manufacturer, Pentair Water Belgium N.V., has the
right to modify the products without previous notice for as
far as their characteristics are not really changed by this.
THESE OPERATING INSTRUCTIONS CONTAIN IMPORTANT INFOR-
MATION ON THE SAFE, PROPER AND ECONOMICAL OPERATION
OF THE SWIMMING POOL PUMPS. STRICT OBSERVATION OF THE
OPERATING INSTRUCTIONS WILL HELP TO AVOID DANGERS, RE-
DUCE REPAIR COSTS AND SHUTDOWN TIMES AND INCREASE
THE RELIABILITY AND WORKING LIFE OF THE PRODUCT.
IMPORTANT SAFETY PRECAUTIONS
Section 1
General information
Check carton for any evidence of damage due to rough
handling in shipment. If carton or any pump components
are damaged, notify the carrier immediately.
Failure to follow the safety instructions may
result in serious adverse health effects, or
even serious or fatal injury. Failure to follow
the safety instructions will in all cases
invalidate all guarantees and liability on the
part of the manufacturer.
This pump is equipped with a mechanical seal.•
Avoid dry run of the pump, as long as the pump •
isnotlledwithwater;
Damage to shaft seal could be the cause by non-•
observance of instructions.
Pleasefollowinstructionsforllingupthepump•
according to installation and instruction manual.
Section 2
Application
Only to be used to circulate swimming pool water.
Section 3
Installation
Install the pump as near to the pool as practical.•
Use a direct and short suction line with continuous •
slope in order to avoid long priming times.
English
The pump should be placed on a at, solid foundation, •
high enough to prevent ooding of the motor.
Install the lter and pump in a sheltered location, ensu-•
ring ventilation and adequate access for servicing.
Do not mount electrical controls directly over pump.•
Provide adequate oor drainage to prevent ooding. •
Size all piping adequately and keep the number of el-•
bows to a minimum.
Independently support the pipe near the suction and •
discharge of the pump in order to reduce the strain on
the pump.
Avoid overtightening pipe connections. Use only pipe •
sealants formulated for plastics. Do not use petroleum
based products. It is essential that the suction line is
free of air leaks. The suction line should always be at
least the same size as the suction inlet of the pump.
Please note: There can be specic needs to use pumps by
swimming pools, garden ponds or such places.
Section 4
Start / Operation
Starting the pump
Fill pump strainer with water to suction pipe level.•
Lubricate the lid O-ring with silicone each time it is re-•
moved.
Energize the motor, the pump will prime. The priming •
time depends on the suction lift and distance to the
pool. Five minutes is a reasonable time.
Pump will not lift more than 2,5 meter. If pump does •
not prime, see troubleshooting guide.
Maintenance
The strainer basket should be daily removed and cleaned.
Never operate the pump without its strainer basket.
Component Check / Interval Remarks
Warning pictograms Visual check / Monthly Replace if necessary
Water supply Check lines and Repair any damage
connections / Monthly immediately
Safety devices Visual check / Monthly Ensure correct
installation / retting
General condition Visual check /Half-yearly Look out for any
of pumps corrosion or damage
Cooling ribs of Clean the cooling ribs to
electric motors maintain the cooling effect /
Half-yearly
Electrical equipment Check / Monthly Rectify loose
connections or
singed cables
immediately. Have all
faults repaired by a
qualied electrician
Preliminary lter Check housing for dirt / Remove all dirt
housing Weekly thoroughly
O-Ring in Visual check / Half-yearly
preliminary lter
cover
