Pentax Optio A20 User Manual

14
1
Getting Started
Powering the Camera
Install the battery provided with the camera.
1 Open the battery/card cover.
Slide the battery/card cover in the direction indicated by the arrow
and flip the cover open .
2 Insert the battery with the 2 symbol facing toward the LCD
monitor while using the side of the battery to press the
battery lock lever in the direction indicated by the arrow.
3 Close the battery/card cover.
1 Open the battery/card cover.
2 Release the battery by using your finger to press the
battery lock lever in the same direction as when you
inserted the battery.
The battery will be ejected. Pull the battery out of the camera.
Installing the Battery
Removing the Battery
If you intend to use the camera continuously for a long period, use
of the AC adapter kit K-AC8 (optional) is recommended. (1p.19)
• Insert the battery correctly. If the battery is incorrectly oriented, it
may cause a malfunction.
• Do not remove the battery when the camera is turned on.
•
If you do not intend to use the camera for a long time, remove the battery.
• If the camera is left without the battery for a long time, the date will be reset.
3
2
1
1
2
Battery
Battery lock
lever
1
2

Pentax Optio A20 Specifications

General

Megapixel	10 MP
Sensor type	CCD
Image sensor size	1/1.8 \
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1024 x 768, 1600 x 1200, 2048 x 1536, 2592 x 1944, 3072 x 2304, 3648 x 2736
Digital zoom	4 x
Focal length range	7.9 - 23.7 mm
Digital SLR	No
Built-in flash	Yes
Camera shutter speed	4 - 1/2000 s
Effective sensor resolution	1037000 pixels
Compatible operating systems	Windows 98/98SE/Me/2000/XP
Focal length (35mm film equivalent)	38 - 114 mm
Focus adjustment	Auto
Normal focusing range	0.35 - ∞ m
Super Macro focusing range	0.06 - 0.15 m
Macro focusing range (wide)	0.12 - 0.4 m
Light metering	Centre-weighted, Spot
ISO sensitivity	64, 100, 200, 400, Auto
Internal memory	22 MB
Compatible memory cards	sd
Maximum memory card size	4 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	232000 pixels
USB version	2.0
Scene modes	beach, Children, Documents, Night, Portrait, Sports, Landscape (scenery)
White balance	auto, daylight, Fluorescent, manual, Shade, Tungsten
Self-timer delay	2, 10 s
Product color	Silver
Battery type	D-LI8
Flash modes	auto, Flash off, Red-eye reduction
Camera shutter type	Electronic

Weight and Dimensions

Depth	23 mm
Width	88.5 mm
Height	54.5 mm
Weight	125 g
