190
8
Appendix
White Balance Auto, Daylight, Shade, Tungsten Light, Fluorescent Light, Manual
Lens Focal Length 7.9 mm - 23.7 mm (equivalent to 38 mm - 114 mm in
35 mm format)
Maximum Aperture f/2.8 - f/5.4
Lens Composition 7 elements in 5 groups (two dual-sided aspherical
elements, one single-sided aspherical element)
Zoom Type Electrically driven
Picture Range
Approx. 65.6 mm
×
48.6 mm (screen is filled) (Super Macro
mode)
Lens Cover Electrically driven
Intelligent Zoom 3.6× at 7M (3072 × 2304) , 4.2× at 5M (2592 × 1944) , 5.3× at 3M
(2048 × 1536) , 6.7× at 2M(1600 × 1200), 10.4× at 1024(1024 × 768),
16.3× at 640 (640 × 480), The ratio of 3× optical zoom included. The ratios
are approximate.
Digital Zoom Capture Mode 5.4× maximum, or equivalent to 16.3× maximum (3×
optical zoom ratio included) in all recorded pixels.
LCD Monitor 2.5-inch TFT color LCD, approx. 232,000 pixels, with LCD backlight, low
reflective type, field of view: approx.100%, wide viewing angle (horizontally
160°, vertically 160°), the brightness of backlight adjustable in two steps or
by holding down the OK/Display button for more than 1 second.
Playback Functions Single-frame, 9 frame index, calendar, enlargement (max. 8×, scrollable),
movie playback, sound playback, histogram display, Select & Delete
Playback Mode Palette (Slideshow, Resize, Cropping, Image/Sound Copy,
Image Rotation display, Color Filter, Digital Filter, Brightness Filter, Movie
Edit, Red-eye Compensation, Voice Memo, Protect, DPOF, Start-up
Screen, Frame Composite)
Color filter
B&W, Sepia, Color filter (Bar display, Eight colors), B&W +
Red, B&W + Green and B&W + Blue.
Digital filter Soft, Illustration, Special Effect 1, Special Effect 2, Slim
Brightness filter Brightness filter
Focusing System Type TTL contrast detection system by sensor, 5-point AF,
Spot AF, or Automatic tracking AF selectable, Focus
lock is possible by pressing the shutter release button
halfway.
Still Picture
Focusing Range
(from lens front)
Normal: Approx. 0.35 m
- ∞ (full zoom range)
Macro: Approx. 0.12 m - Approx. 0.4 m (at full wide-
angle to 11.5 mm)
Super Macro: Approx. 0.06 m - Approx. 0.15 m (full
wide-angle)
Infinity:
∞ (full zoom range)
Pan focus: Approx. 2.3 m - ∞ (full wide-angle), Approx.
9.3 m -
∞ (full telephoto)
Manual Focus: Approx. 0.06 m - ∞ (full wide-angle),
Approx. 0.35 m - ∞ (full telephoto)
Movie Focusing
Range
(from lens front)
Normal: Approx. 0.12 m
- ∞ (full wide-angle), Approx.
0.35 m -
∞ (full telephoto)
Macro: Approx. 0.12 m - 0.4 m (at full wide-angle to
11.5 mm)
Super Macro: Approx. 0.06 m - Approx. 0.15 m (full
wide-angle)
Infinity: ∞ (full zoom range)
Pan focus: Approx. 0.9 m -
∞ (full wide-angle), Approx.
3.7 m - ∞ (full telephoto)
Manual Focus: Approx. 0.06 m - ∞ (full wide-angle),
Approx. 0.35 m - ∞ (full telephoto)
