6500 Series Purge and Pressurization System
I/O Manual
10
2.4 Technical specications
General specifications
Operating mode User programmable
Number of volume exchanges 5 to 19
Hazardous environment Gas, dust, gas and dust Note: Gas and dust are
Electrical specifications
Supply
Rated power requirement Universal AC/DC power requirement
100 to 240 VAC / 50 to 60 Hz / 200 mA
20 to 30 VDC / 600 mA
Um = 250 V
Connections
EPCU Terminal blocks and grounding screw
UIC 4-pin micro connector and cable (provided), for the
6500-01-PM02, cable length is 5 meters.
Input type Intrinsically safe, maximum cable 60 meters at 50
pf/ft and 0.2µH/ft
Inputs
Input 1 Voltage free contact or namur proximity sensor
Input type Intrinsically safe
Switch input (IS)
Uo = 9.56 V
Io = 19.4 mA
Co = 3.6 µF
Lo = 90 mH
Po = 46 mW
Input RTD (1) 2-wire, PT100 RTD
RTD input (IS)
Uo = 5.88 V
Io = 3.34 mA
Co = 43 µF
Lo = 100 mH
Po = 5 mW
Input type Intrinsically safe, Ex ib
Output
AUX output
Output type Voltage free contact outputs, SPDT configuration
Inrush current
2 A
Contact loading 2 A @ 240 VAC, resistive, 2 A @ 24 VDC
Note: External fusing is required at 3 AC or DC /
1500 A breaking current, Um = 250 V
Enclosure output
Output type Voltage free contact outputs, 2 N.O. configuration
Inrush current 8 A
Continued on next page
