Pepperl+Fuchs 6000 SERIES Manual

6500 Series Purge and Pressurization System
I/O Manual
56
12 Purge 6500 user-interface programming worksheet
— SETUP — PASSWORD — PURGE SETTINGS — PURGE TYPE — Px
(button) — Py
—
ENCLOSURE
VOLUME — USER DEFINED —
—
NUMB OF
EXCHANGES — 4 - 19 —
— ENVIRONMENT — GAS
— DUST
— BOTH
— PRESSURES — MAX OVER PRESSURE —
— LOW PRESSURE —
— MIN OVER PRESSURE —
— TIMERS — SHUTDOWN TIME —
—
UNLOCK DOOR
TIMER —
— OPERATION MODE — SA
— FA
—
VENT FLOW
CONTROL — STANDARD
— DILUTION
— VALVE CONTROL — DIGITAL
— PROPORTION
—
DILUTION
SETTINGS — PURGE FLOW
— DILUTION FLOW SP
— MIN FLOW SP
— UNITS — IMPERIAL —
SETTING CORRECT
Y/N
— METRIC —
SETTING CORRECT
Y/N
