6500 Series Purge and Pressurization System
I/O Manual
54
10 Model number designation
The 6500 control unit
6500 - 01 - EXT1 - PNO - LNO
LNO: I.S. connections, (5) M12 threads
PNO: Power connections, (4) M20 threads
EXT1: External mount, UIC and EPCU together
PM01: Panel mount, UIC and EPCU together
PM02: Panel mount, UIC separate from EPCU
6500 Control unit
The EPV-6500 UIC
6500 - 01 - UIC - EXT
EXT: For External mounted 6500 control unit
PM0: For Panel or Internal mount 6500 control unit
UIC: User-Interface Controller
6500 series vents
Note!
6500-01-UIC-… comes with standard 6500-01 control unit. Nomenclature is only used when ordering
replacements.
The EPV-6500 relief vent
EPV- 6500 - AA - 01
01: High flow rate, low enclosure pressure, high leakage rate
03: Medium flow rate, medium enclosure pressure, medium leakage rate
05: Low flow rate, high enclosure pressure, low leakage rate
07:
08:
AA: 5000 series aluminum body and cap
SS: 5000 series aluminum body and 316L stainless steel cap
EPV-6500 series vents
Note
