6500 Series Purge and Pressurization System
I/O Manual
22
2.7 Mounting of the control unit – external, internal, internal with remote
UIC mounting
PM01 internal mounting
PM02 component kit
Warning!
When mounting the 6500 control unit to a wall, the mounting method should be able to
handle 4 times the gross weight of the 6500 unit.
Setup
Exit
Stats
Start
Set
6500 Series Type px/py
Safe
Pressure
Enclosure
Power
Rapid
Exchange
System
Bypass
Alarm/
Fault
Key
