6500 Series Purge and Pressurization System
I/O Manual
25
n/a
EPV-6500-__-08 n/a
Breaking pressure
EPV-6500-__-01 2.0 mbar (0.8” wc)
EPV-6500-__-03 3.5 mbar (1.4” wc)
EPV-6500-__-05 3.8 mbar (1.5” wc)
n/a
EPV-6500-__-08 n/a
Accuracy
Pressure reading
At 25 °C ± 0.025 mbar (± 0.01” wc)
Full temperature range ± 0.125 mbar (± 0.05” wc)
Flow reading
EPV-6500-__-01, 03, 05 Standard vent, ± 28 l/min (± 1 scfm)
Continuous vent, ± 2.6 l/min (± .1 scfm)
Ambient conditions
Ambient temperature
Storage temperature
Relative humidity 5 … 90%, noncondensing
Vibration resistance 5 … 100 Hz, 1g, 12 m/s², all axes
Impact resistance 30g, 11ms, all axes
Mechanical specications
Degree of protection IP66 for the EPV-6500 vent, Type 4x for the
mounting to the enclosure
Materials
EPV-6500-AA-__ Body: 6000 series, aluminum anodized
Cap: 5000 series, aluminum anodized
EPV-6500-SS-__ Body: 6000 series, aluminum anodized
Cap: 316L stainless steel
Spark arrestor 304 stainless steel
Mass Approx. 1.4 kg (3.1 lb)
Dimensions
Mounting 1½” NPT knockout (50.8 mm (2”) hole) with seal nut
included
3.2 Technical specications (continued)
