6500 Series Purge and Pressurization System
I/O Manual
45
• Input settings
INPUT 1 INPUT 1 FUNCTION DISABLED
IMMEDIATE SHTDN
OVERLOAD
CONTROL PWR RELAY
CONTROL OUTPUT 1
CONTROL VALVE
SYSTEM BYPASS
INPUT 1 SRM SRM YES, NO
INVERT INPUT 1? INVERT YES, NO
PRESS AS INPUT PRESS FUNCTION DISABLED
CONTROL OUTPUT 1
CONTROL VALVE
ON PRESSURE XX.XX
OFF PRESSURE XX.XX
OFF DELAY TIME
TEMP INPUT TEMP INPUT 1 TEMP FUNCTION DISABLED
IMMEDIATE SHTDN
OVERLOAD
CONTROL PWR RELAY
CONTROL OUTPUT 1
CONTROL VALVE
ALARM
ON SET POINT XX °C or °F
OFF SET POINT XX °C or °F
TEMP INPUT 2 TEMP FUNCTION DISABLED
IMMEDIATE SHTDN
OVERLOAD
CONTROL PWR RELAY
CONTROL OUTPUT 1
CONTROL VALVE
ALARM
ON SET POINT XX °C or °F
OFF SET POINT XX °C or °F
