VisuNet FLX Panel
Product Description
2021-04
17
Relative humidity max. relative humidity 93% at 40°C (non-condensing) according to
EN60068-2-78
Climatic condi-
tions
Passive cooling, no rotating parts
Altitude Operating altitude max. 2000 m
Shock resistance 18 shocks 15 g, 11 ms all axis, IEC 60068-2-27
Vibration resis-
tance
10 ... 150 Hz, +/- 0.075 mm, 1 g, 10 cycles per axis according to EN60068-
2-6
Mechanical specifications
Degree of protec-
tion
Front side: IP66
Back side: IP20
Type 4X indoor
Material Front bezel: Stainless steel AISI304 (glass, silicone gasket)
Backside: Painted aluminum sheet metal
Installation Panel mount (additional Mounting Kits available) installed in boundary wall,
in cabinet wall or special enclosure
Mass 22GT, 22FC and 19SC: 6.5 kg
15FC: 4.4 kg
Dimensions 22 inches: 567 mm x 358 mm x 68 mm
19 inches: 485.7 mm x 410.5 mm x 68 mm
15 inches: 434 mm x 283.4 mm x 67 mm
For cut out dimensions refer to the panel mount manual.
Data for application in connection with hazardous areas (pending)
EU-type examination certificate
Marking Certificate in preparation.
II 3 G Ex ec [ic] IIC T4 Gc
II 3 D Ex tc [ic] IIIC T85°C Dc
International approvals (pending)
UL approval
Approved for Certificate in preparation.
Ordinary location
acc. UL 61010-1 and UL 61010-2-201
Hazardous location
Class I, DIV 2, GPS A-D
Class II, DIV 2, GPS F-G
Class III
Class I, ZN 2, IIC T4
Class II, ZN 2, IIIC T85°C
Class III
IECEx approval
IECEx certificate Certificate in preparation.
Ambient conditions
