VisuNet FLX Panel
Mechanical Installation
4 Mechanical Installation
4.1 Unpacking
The VisuNet FLX panel comes with its core components preassembled. These components
consist of a display unit (DPU) and a computing unit (thin-client unit (TCU), PC unit (PCU) or
direct monitor unit (DMU)).
Figure 4.1
Note
Recommendation for use: Carry out the installation of the device at the installation location with
at least two persons.
Note
Handling the VisuNet FLX components without gloves may cut fingers, hands, or wrists. Wear
gloves always during installation.
Caution!
Scratches and damage!
FLX components may become scratched or damaged if they are placed onto or slid across
hard surfaces.
Caution!
Restrictions resulting from scratched DPU screen!
Scratches in the DPU screen weaken the glass structure. If the surface is damaged in any way,
return the DPU to Pepperl+Fuchs at once and replace it with a new one. See chapter 7.2 for
information about removing the DPU.
