10
Fig. 16
INSTALLATION INSTRUCTIONS
Only the pressure regulator and hose assembly supplied with the grill should be used. Any replacement
pressure regulator and hose assembly must be specified by the grill manufacturer.
This grill is configured for Liquid Propane. Do not use a Natural Gas supply.
Total gas consumption (per hour) of the 720-0533 Liquid Propane gas grill with all burners set on “HI”:
Main burners 52,000 BTU/Hr.
Rear burner 10,000 BTU/Hr.
Side burner 12,000 BTU/Hr.
Total 74,000 BTU/Hr.
GAS HOOK-UP
The installation of this appliance must conform with local codes or, in the absence of local codes, with either the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, National Gas Propane Installation Code, CSA B149.2.
Installation in Canada must be in accordance with the Standard CAN/CGA-B149.2 (installation code for gas burning
appliances and equipment) and local codes.
LIQUID PROPANE CYLINDER REQUIREMENTS
(20 lb. Cylinder)
A dented or rusty Liquid Propane cylinder may be hazardous and should be checked by your supplier. Never use a
cylinder with a damaged valve. The Liquid Propane cylinder must be constructed and marked in accordance with the
specifications for Liquid Propane cylinders by the United States Department of Transportation (DOT) or the National
Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods
Commission.
The 20 lb. cylinder must have a shut off valve terminating in a valve outlet specified, as applicable, for connection type
QCC1 in the standard for compressed gas cylinder valve outlet and inlet connection ANSI/CGA-V-1.
Storage of an outdoor cooking gas appliance indoor is permissible only if the cylinder is disconnected and removed
from the outdoor cooking gas appliance. The cylinder system must be arranged for vapor withdrawal. The cylinder
must include a collar to protect the cylinder valve.
Manifold pressure: (operating) 10 inches water column (W.C.), (non-operating) 11.2 inches water column (W.C.).
