Touch panel Flow Chart
Attachment 1:
Warning Shown on Touch Panel Explanation
LCD Display Err 1 Error on Main Burner 1-2’s adjusting valves.
Err 2 Error on Main Burner 3-4’s adjusting valves.
Err 3 Error on side burner adjusting valves.
Err 4 Error on rear burner adjusting valves.
Err 5 Error on automatic safety valve.
Flame-
Indication
LED Light
All Lights 1. No gas is burned; the gas manifold is obstructed.
2. Error on automatic safety valve.
Main Burner 1-2’s Light 3. Same as above (for “All Lights”).
4. Gas cannot be reached to the corresponding burners.
5. Error on corresponding igniters.
6. Error on corresponding electrodes.
7. Improper electrode sensing distances.
8. Error on corresponding adjusting valves.
Main Burner 3-4’s Light
Side Burner’s Light
Rear Burner’s Light
Start
Switch ON the
mechanical
ON/OFF Switch
Any error?
System can be
operated. (Proceed
to Attachment 2)
System can not be operated.
Error code is shown on the LCD
display, and corresponding
flame-indication lights will flash
(See Attachment 1). Restart is
required for the grill to operate
again.
No (1 Buzz) Yes (3 Buzzes)
Self Inspection
18
