Perfect Flame 720-0533 - LIGHTING AND IGNITION; Electrical ON;OFF Button Function

Lighting Instruction
Electrical ON/OFF Button
A)
Electrical
ON/OFF Button
E)
REAR BURNER “R”
Button
B)
MAIN BURNER (1-2)
Control Button
(Activation Button,
HI Button, and
LO Button)
C)
MAIN BURNER (3-4)
Control Button
(Activation Button,
HI Button, and
LO Button)
D)
SIDE BURNER
Control Button
(“S” Button,
HI Button, and
LO Button)
F)
TIMER Control Button
(Activation Button, “+”
Button, and “-” Button)
Main Power
LED Light
Electrical ON/OFF
Button
• Electrical ON/OFF Button controls the power supply of the control panel system. After pressing the button for 3
seconds, the safety valve will be opened, and the system will be ready to operate. The Main Power LED Light will
be turned on to indicate that the power is ON. When power is ON, press the button for 3 seconds to turn OFF.
14
