PerkinElmer Lambda 365 Assembly/Installation Instructions

09931295C
2
Dimensions and Specifications
Description
Configuration of the Magnetic Stirrer Assembly
Figure 2 Configuration
Physical Characteristic Specification
Dimensions (mm) 65 (W) x 50 (D) x 45(H)
Weight (g) 79
Speed (rpm) 120 ~ 1,200
Stirring Power (W) 10
Operating Condition
0~40℃, 80% Humidity
Power AC 100-240 V / 50-60 Hz / 0.4 A

PerkinElmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 V AC, 50/60 Hz
Wavelength Accuracy	±0.3 nm
Wavelength Repeatability	±0.1 nm
Wavelength Reproducibility	±0.1 nm
Photometric Repeatability	±0.001 Abs
Baseline Flatness	±0.0005 Abs
Baseline Stability	<0.0003 Abs/hour (after warm-up)
Data Interval	0.1 - 5 nm
Light Source	Tungsten halogen lamp and deuterium lamp
Sample Compartment	Standard 10 mm cell holder
Detector	Silicon Photodiode
