PerkinElmer Lambda 365 Assembly/Installation Instructions

09931295C
3
Compatible Lambda 265 Cell Holders to Magnetic Stirrer Assembly
Accessory Drawing
Single Cell Holder
Water Jacketed
Single Cell Holder
Compatible Lambda 365 Cell Holders to Magnetic Stirrer Assembly
Accessory Drawing
Single Cell Holder
Water Jacketed
Single Cell Holder
Micro Cell Holder

PerkinElmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 V AC, 50/60 Hz
Wavelength Accuracy	±0.3 nm
Wavelength Repeatability	±0.1 nm
Wavelength Reproducibility	±0.1 nm
Photometric Repeatability	±0.001 Abs
Baseline Flatness	±0.0005 Abs
Baseline Stability	<0.0003 Abs/hour (after warm-up)
Data Interval	0.1 - 5 nm
Light Source	Tungsten halogen lamp and deuterium lamp
Sample Compartment	Standard 10 mm cell holder
Detector	Silicon Photodiode
